L-Acoustics A15 Series User Manual

Electro-acoustical description
Electro-acoustical description
Adjustable ns
A15 Focus and A15 Wide feature L-Fins to adjust the waveguide directivity to one of four settings: 110° / 70° symmetric
or 90° asymmetric (35°/55° or 55°/35°).
The same [A15] preset drives all directivity settings of both enclosures.
Within a line source, combine A15 Focus and A15 Wide with custom directivity settings to improve SPL mapping and
throw capability.
110° setting
55°
55°
12 A15 owner's manual (EN) version 1.2

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
