L-Acoustics A15 Series User Manual

Rigging procedures
Disassembly
Procedure
1. Lower the array to the ground.
2. On each A15-LIFT, move the shackle to the safe pickup point (hole 11).
1 2
3
4
5
6 7 8 9 10
11 12
13
14
15 16
17
setup point
FRONT
Make sure the pickup points are on hole 11 before lifting the array.
3. Raise the array until the bottom rigging is accessible.
4. Disconnect the enclosures at the bottom.
SHLAK!
Make sure all unused rigging arms are in storage position.
5. Lower the array to the ground.
A15 owner's manual (EN) version 1.2 63

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
