L-Acoustics A15 Series User Manual

Rigging system description
17 holes are available for site angle adjustment. They are compatible with Ø12 mm shackles WLL 1 t (two provided) and
CLAMP250.
A15-LIFT pickup point
Select the same pickup point on each A15-LIFT within an array of up to 6 enclosures.
For larger arrays, refer to Radial arrays of 7 enclosures and more (p.95).
Hole 11 serves as a setup point in the radial array procedure (see Flying a radial array with A15-LIFT (p.58)).
It is identied by a mark on the label.
1 2
3
4
5
6 7 8 9 10
11 12
13
14
15 16
17
setup point
FRONT
A15 owner's manual (EN) version 1.2 31

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
