Rigging system description
The opening angle of A-TILT can be adjusted between 12.5° and 25°.
The label displays the opening angle of the accessory and not the site angle of the enclosure. Refer to Stacking A15
Wide/Focus on KS21 with A-TILT (p.67) for the list of realized site angles.
Four
11 mm holes are available to secure the assembly to the oor.
11 mm hole (x4)
A15 owner's manual (EN) version 1.2 33

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the L-Acoustics A15 Series and is the answer not in the manual?

L-Acoustics A15 Series Specifications

General IconGeneral
Nominal impedance8 ohms
Frequency Response44 Hz - 20 kHz
Maximum SPL141 dB
AmplificationLA4X / LA8 / LA12X
Weight33 kg
LF Transducers1 x 15'' neodymium
HF Transducers1 x 3'' diaphragm compression driver
Power Handling800 W
Connectors2 x 4-point speakON
