L-Acoustics A15 Series User Manual

Rigging procedures
Prepare KS21-CHARIOT
Make sure the KS21-CHARIOT brakes are not engaged.
Make sure the KS21-CHARIOT rigging arms are in the open position.
Proceed slowly when lowering the array.
2. Lower the array until it rests on KS21-CHARIOT.
3. Secure the bottom enclosure to KS21-CHARIOT.
SHLAK!
4. Disconnect a stack from the array on both sides.
Make sure both linking points are disconnected before lifting the array.
5. Lift the assembly and put the stack aside.
6. Repeat the procedure.
A15 owner's manual (EN) version 1.2 55

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
