L-Acoustics A15 Series User Manual

Rigging procedures
Risk of crushing
Hold the top enclosure when the angle pins are removed.
Accompany the assembly movement downwards.
8. Adjust the site angle.
Insert the angle pins in the selected opening angle on both sides.
20°
9. Optionally, secure additional enclosures on top of the assembly.
SHLAK!
Final check
Visually check that no yellow labels are visible.
Manually check that all linking points are secured.
70 A15 owner's manual (EN) version 1.2

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
