L-Acoustics A15 Series User Manual

Specications
A15-LIFT specications
Description Rigging element for horizontal deployment of A15
2 × Ø12 mm shackles WLL 1 t
Weight (net) 2.3 kg / 5.1 lb
Material high grade steel with anti-corrosion coating
A15-LIFT dimensions
139 mm / 5.5 in
50 mm / 2 in
25 mm / 1 in
629 mm / 24.8 in
A15-RIGBAR specications
Description Rigging bar and pullback for A15 and KS21
2 × Ø12 mm shackles WLL 1 t
Weight (net) 4.6 kg / 10 lb
Material high grade steel with anti-corrosion coating
A15-RIGBAR dimensions
750 mm / 29.5 in
64 mm / 2.5 in 18 mm / 0.7 in
89 mm / 3.5 in
10 mm / 0.4 in
86 A15 owner's manual (EN) version 1.2

L-Acoustics A15 Series Specifications

General

Nominal impedance	8 ohms
Frequency Response	44 Hz - 20 kHz
Maximum SPL	141 dB
Amplification	LA4X / LA8 / LA12X
Weight	33 kg
LF Transducers	1 x 15'' neodymium
HF Transducers	1 x 3'' diaphragm compression driver
Power Handling	800 W
Connectors	2 x 4-point speakON
