System components
System components
Loudspeaker enclosures
K2 3-way full-range active WST enclosure
K1-SB K1 system subwoofer 2×15"
SB28 High power subwoofer: 2 x 18''
KS28 Flyable subwoofer 2 x 18''
Kara 2-way modular WST enclosure
Powering and driving system
LA4X / LA8 / LA12X Amplied controller with DSP, preset library and networking capabilities
LA-RAK Touring rack containing three LA8 and power, audio and network distribution
LA-RAK II Touring rack containing three LA12X, LA-POWER II for power distribution and LA-PANEL II for
audio and network distribution
Refer to the LA4X / LA8 / LA12X user manual for operating instructions.
Loudspeaker cables
SP cables 4-point speakON loudspeaker cables (4mm² gauge)
SP cables come in four sizes: SP.7 (0.7m/2.3ft), SP5 (5m/16.4ft), SP10 (10 m/32.8ft) and
SP25 (25m/82ft)
SP-Y1 breakout cable for two passive enclosures (2.5mm² gauge) provided with a CC4FP adapter
4-point speakON to 2 × 2-point speakON
DO 8-point PA-COM loudspeaker cables (4mm² gauge)
DO cables come in three sizes: DO.7 (0.7m/2.3ft), DO10 (10m/32.8ft) and DO25
(25m/82ft)
DOSUB-LA8 breakout cable for four passive enclosures (4mm² gauge)
8-point PA-COM to 4 × 2-point speakON
DOFILL-LA8 breakout cable for two 2-way active enclosures (4mm² gauge)
8-point PA-COM to 2 x 4-point speakON
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA4X / LA8 / LA12X user manual for detailed instructions about the whole cabling scheme,
including modulation cables and network.
Rigging elements
K2-BUMP Structure for ying K2 arrays (incl. 1 extension sling + 1 laser adapter)
K2-BAR Extension bar for K2-BUMP
K1-DELTA Rigging accessory for rear attachment of 2 motors to K1-BUMP
K2-JACK 4 tilt adjustment screw jacks + bar for K2-CHARIOT
K2-LINK Rigging accessory for rear attachment of K2 below K1
K2-RAKMOUNT 4 mounting cradle for LA-RAK (incl. rack stabilizer)
K1-BPCHAIN Adjustable sling for K1-BUMP or K2-BUMP
10 K2 owner's manual (EN) version 1.1

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
