L-Acoustics K2 User Manual

Rigging procedures
J - Attaching a block of four K2 under K2
Procedure
Preset inter-enclosure angles
Preset the inter-enclosure angles before performing this procedure. Refer to B - Preset the inter-enclosure angles
(p.73).
1. Attach the front rigging arm on both sides:
a) Rotate the arm to align its hole with the K2 rigging hole.
100 K2 owner's manual (EN) version 1.1

L-Acoustics K2 Specifications

General

Frequency Response	35 Hz - 20 kHz
Max SPL	147 dB
Transducers	2 x 12" LF, 4 x 6.5" MF, 2 x 3" HF
Nominal Impedance	8 ohms
Amplification	LA8 / LA12X
Weight	56 kg
Type	3-way active WST line source
Components	12" LF, 6.5" MF, 3" HF
Connectors	2 x 4-point speakON
