Inspection and preventive maintenance
K2 array with K2-CHARIOT and K2-JACK
Refer to Inspection references (p.49).
Ball-locking pins (p.49)
Rigging check (p.54)
Grill safety (p.53)
rear rigging arms rotate
correctly
the locking handles can be
tightened and loosened by
hand
turn the hand wheels:
the central part is raised
(clockwise) or lowered
(counter-clockwise)
check the integrity of the
quarter-turn locking system
46 K2 owner's manual (EN) version 1.1
