Loudspeaker congurations
Loudspeaker congurations
K2 line source
Deployed as a line source, the system operates over the nominal bandwidth of the K2 enclosure, with an adjustable
horizontal directivity.
Two congurations are possible:
• K2 line source
• K2/K1-SB line source: enhanced LF throw
The [K2 70], [K2 90] and [K2 110] presets allow for a reference frequency response in long throw applications. Each
preset is dedicated to a horizontal directivity setting.
By providing the K1-SB with the same frequency response as the K2 low section, the [K1SB_X K2] preset allows the K1-SB
enclosure to be used as an LF line source element, increasing the length of the sub-low line source.
Amplied controllers compatibility
LA4X LA8 LA12X
K2
✓ ✓ ✓
K1-SB -
✓ ✓
KS28 - -
✓
SB28 -
✓ ✓
Standalone K2 line source
[K2 70] / [K2 90] / [K2 110]
[PRESET]
Enclosure K2
Preset [K2 70] [K2 90] [K2 110]
Frequency range (-10 dB) 35 Hz - 20 kHz
