Rigging procedures
F - Stacking K2 on K2-BUMP
min number of operators 2
Procedure
1. Prepare a block of 4 K2. Refer to A - Preparing a block of 4 K2 (p.69).
2. Preset the inter-enclosure angles. Refer to B - Preset the inter-enclosure angles (p.73).
3. Prepare the K2 block top enclosure:
a) Take out and lock the rear and front rigging arms.
b) Dene the K2 stack site angle with the rear rigging arm.
For the top enclosure of the stack, select a value between 0.25 and 7.5 and subtract 3 to obtain the nal site
angle. For the other enclosures, select the angle normally.
Final site angle for top enclosure
authorized angles nal site angles
0.25° -2.75°
1° -2°
2° -1°
7.5° 4.5°
3° 0°
4° 1°
5° 2°
-2.75°
0°
+2°
+1°
+4.5°
-2°
-1°
