Rigging procedures
I - Attaching a block of four K2 under K2-RIGBAR
Procedure
Preset inter-enclosure angles
Preset the inter-enclosure angles before performing this procedure. Refer to B - Preset the inter-enclosure angles
(p.73).
1. Hang the LA-SLING2T to the motor hook.
Make sure the chains are not twisted.
2. Attach the bar to the sling using the two 3.25 t WLL shackles.
Use the interior holes of the bar.
The external holes are dedicated to safety slings.
K2 owner's manual (EN) version 1.1 97
