L-Acoustics K2 - K - Attaching a Block of Four K2 under a K1 System Element

Rigging procedures
K - Attaching a block of four K2 under a K1 system element
Procedure
K1 / K1-SB must always be on top of a K2 array.
Preset inter-enclosure angles
Preset the inter-enclosure angles before performing this procedure. Refer to B - Preset the inter-enclosure angles
(p.73).
1. Attach the front rigging arm on both sides:
106 K2 owner's manual (EN) version 1.1
