Rigging system description
KARADOWNK2
KARADOWNK2 is a rigging interface for Kara under a K2 array.
The four tabs on the top are compatible with the K2 rigging system.
The four slits tted with ball-locking pins accommodate the Kara rigging arms.
slit and ball-locking pin (x4)
tab (x4)
Elements for LA-RAK/LA-RAK II rigging
K2-RAKMOUNT
The K2-RAKMOUNT is designed to stack one or two LA-RAK/LA-RAK II on top of a own array. It is composed of four
rails and a stabilizer.
The rails are screwed on the K2-BUMP. Their number and position depend on the number of racks. The K2-RAKMOUNT
must be used along with either one or two K2-BAR.
26 K2 owner's manual (EN) version 1.1
