L-Acoustics K2 - O - Rigging a Kara DownLl Array under a K2 Array

Rigging procedures
O - Rigging a Kara downll array under a K2 array
Type of deployment own array
Rigging accessories KARADOWNK2
Min number of operators 2
Assembly
About this task
Reference rigging manuals
This procedure is complementary to the rigging instructions available in the main system rigging manuals.
Refer to the Kara owner's manual for more details.
Prerequisite
• Prepare and raise a K2 array. Refer to A - Preparing a
block of 4 K2 (p.69).
• Prepare an array of three Kara with 0° inter-enclosure
angles.
• Position the Kara array under the K2 array.
Make sure the latches on the bottom K2 are in storage position.
Procedure
1. Take out the four rigging arms on the top Kara enclosure:
a) Lock the front rigging arms in linking position.
K2 owner's manual (EN) version 1.1 123
