Rigging procedures
b) Slide up the rear rigging arms and select the same inter-element angle, from 0° to 10°.
2. Secure a KARADOWNK2 on top of the Kara array.
Position the higher ledge at the rear.
Secure the Kara rigging arms inside the slits with the ball-locking pins.
x4
3. Lower the K2 array as close as possible to the assembly without resting on it.
124 K2 owner's manual (EN) version 1.1
