L-Acoustics K2 - D - Changing the Position of the K2-CHARIOT Rear Rigging Arm

Rigging procedures
D - Changing the position of the K2-CHARIOT rear rigging arm
min number of operators 2
Procedure
Tipping hazard
When the rear rigging arms are unpinned, hold the enclosures on both sides.
1. On both sides, remove the rear rigging arm pin.
2. Push the enclosures to free both arms.
80 K2 owner's manual (EN) version 1.1
