Loudspeaker congurations
K2/K1-SB line source
[PRESET]
[K1SB_X K2]
[K2 70] / [K2 90] / [K2 110]
[PRESET]
Enclosure K2 K1-SB
Preset [K2 70] [K2 90] [K2 110] [K1SB_X K2]
Frequency range (-10 dB) 35 Hz - 20 kHz
Recommended ratio 3 K2 : 1 K1-SB
Minimum line length 12 K2 + 4 K1-SB
When using [K2 70], [K2 90], or [K2 110] with [K1SB_X K2], do not add any delay value between the K2 and
K1-SB elements of a same line source.
