Corrective maintenance
D/R - RIGGING PINS
Tools
• riveting pliers
Repair kit
KR PIN1542
Kit 2 x pin 1542
×2 ×2
S142 1542
M4×10 rivet round head ball-locking pin Ø5/8" with lanyard
Exploded view
For safety reasons, always use the new screws and spare parts provided in the KR.
160 K2 owner's manual (EN) version 1.1
