Loudspeaker congurations
Line source with K1-SB behind
[PRESET]
[K1SB_60]
K2 LINE SOURCE /
K2/K1-SB LINE SOURCE
1.5 to 2 m
(5 to 7 ft)
Enclosure K2 K1-SB in line source K1-SB as subwoofer
Preset [K2 70][K2 90][K2 110] [K1SB_X K2] [K1SB_60]
Frequency range (-10 dB) 30 Hz - 20 kHz
Recommended ratio 3 K2 : 2 subwoofers
Recommended spacing
between front faces
Between 1.5 m (5 ft) and 2 m (7 ft)
Delay values
Do not forget to add the pre-alignment and geometric delays depending on the conguration.
When using [K2 70], [K2 90], or [K2 110] with [K1SB_X K2], do not add any delay value between the K2 and
K1-SB elements of a same line source.
Geometric delays
1.5 m (5 ft) Line source = 4.5 ms
2 m (7 ft) Line source = 6 ms
