Rigging procedures
Procedure References
1. Prepare all the blocks of 4 K2 necessary to build the array. A - Preparing a block of 4 K2 (p.69)
2. Preset the inter-enclosures angles. B - Preset the inter-enclosure angles
(p.73)
3. Place and open a K-BUMPFLIGHT under the motor.
4. If necessary, attach one or two K2-BAR to the K2-BUMP. G - Attaching K2-BAR to K2-BUMP (p.89)
5. If necessary, stack one or two LA-RAK / LA-RAK II on the K2-BUMP.
• Place K2-BUMP to the ground.
• Stack the LA-RAK / LA-RAK II on the K2-BUMP.
• Raise the K2-BUMP.
M - Mounting LA-RAK/LA-RAK II on K2-
BUMP (p.115)
6. Prepare the pickup points. Refer to Soundvision for the number and
position of the shackles.
7. Lift the assembly so you can position a block of four K2 under it.
8. Attach the block of four K2 to the K2-BUMP. H - Attaching a block of four K2 under K2-
BUMP (p.92)
9. Lift the assembly so you can position a block of four K2 under it.
Verify that no yellow label is visible on both sides of the array.
10. Attach the block of four K2 enclosures to the bottom of the array. J - Attaching a block of four K2 under K2
(p.100)
Verify that the rear rigging arms are secured by pins and that no
yellow label is visible on the front.
11. Repeat the two previous steps until the array is complete.
12. If necessary, implement a pullback with K2-RIGBAR. N - Using a K2-RIGBAR to implement a
pullback (p.120)
13. Raise the array to its nal trim height.
14. Adjust site and azimuth angles.
64 K2 owner's manual (EN) version 1.1
