Rigging procedures
2. Attach the K2-JACK to the K2-CHARIOT:
a) Insert the K2-JACK studs through the K2-CHARIOT.
b) Raise and turn the K2-JACK handles to secure the locking system.
Dust
During the K2-JACK stabilizers rst use dust will come off the threaded rod. It is expected and does not
indicate a malfunction.
3. Prepare the K2-JACK stabilizers.
Rotate the threaded rod counter-clockwise so the central part of the stabilizer is closest to the base.
K2 owner's manual (EN) version 1.1 77
