L-Acoustics KARA MODULAR WST SYSTEM User Manual

KARA_SRM_EN_1-0
w w w . l - a c o u s t i c s . c o m
55
5555
55
11. Separate the platform from KARA#1 as follows:
a. Remove both KARA-MINIBU front R-BLP.
b. If KARA-ANGARMEX are attached to the platform, remove both T-BLP from them.
Otherwise, remove both KARA-MINIBU rear R-BLP.
c. Separate the platform from KARA#1.
d. If KARA-ANGARMEX are attached to the platform, remove them by removing both KARA-MINIBU rear
R-BLP.
e. Re-insert the four R-BLP into the KARA-MINIBU holes.
Figure 62: Separating KARA-MINIBU from KARA#1
Rear
extension
configuration
without KARA-ANGARMEX
Rear
ext
ension
configuration
with KARA-ANGARMEX
(x4)
(x2)
(x2)
c.
b.
a.
e.
b.
c.
