Inspection and preventive maintenance
d) Pull on the rear latches of L2 while extending the rear rigging arms.
The rear rigging arms can be deployed.
Release the latches.
The rigging arms are locked in position.
SHLAK!
e) Press the buttons on both sides of L2-BUMP to activate the automatic locking system.
The latches retract (no yellow label visible).
SHLAK!
L2 owner's manual (EN) version 5.0 73
