USER’S MANUAL OF LK-330E
LABEL & MARK INDUSTRIES COMPANY
52
Then sent -2.0~+2.0 can to adjust the position of printer head.
For example:
Now the printer head position is -1.0. If input “0.2” the printer head position will
move upwards 0.2mm. The position is -0.8mm.
Cutter position Adjustment
Choose Cutter +0.0 and the screen will display as follows:
Then sent -100.0~+100.0 can to adjust the position of cutter. The unitage
1=0.0847mm.
For example:
If input -10 the cutter line position will move 0.847mm to left.
Length Adjustment
When completing printing, the machine will display as follows:
For example:
If the measured total length of these four printings is 101.5mm, you just enter “101.5”
-2.0 至+2.0
调整为：
Adjust Range
-100.0 to 100.0:
Total length of Printings:
Actual length:
