4.4 - AUTOMATIC MIXING
This Function allows a timer to be programmed that can be used, during
the execution of a Recipe, to check the mixing time of the Ingredients
loaded in the mixer wagon.
During weighing, the operation is interrupted in the preset position and
resumes at the end of the count-down of the programmed time. The
activation of the timer is signalled on the display with the lighting up of
the d symbol. If the [
MIXING
] code is programmed in the Recipe, the
execution time will correspond to the value of the programmed time.
If however the [
MIXADJ
] code is programmed, the execution time will
be corrected in relation to the speed of the augers as identified by the
Proximity Speed.
• Recipe Execution Activity.
1. In the Recipe Programming Activity, from the display select the
Ingredient/Unload that precedes the beginning of the Automatic Mixing
by pressing the Ingr., Ingr. and e or Block and Ingr. keys.
2. Program the [
MIXING
] or [
MIXADJ
] Name by using the Alphanumeric
Writing (2FN). To simplify the operation, inside the Alphanumeric Writing
recall the desired Name from the Ingredient/Unload Name Archive by
pressing the q z (e) keys. After selecting the desired Name, press the
OK key to confirm.
3. Program the desired minutes (max. 120) by pressing the q z (e) keys.
• It is possible to program more than one Automatic Mixing in the same
Recipe.
• If the equipment is supplied with the Power Outputs and if the Power
Output Preference (code 52) is set to Mixing, during the count-down the
outputs Out 1, Out 2 and Out 3 will activate/deactivate depending on the
times set in the Mixing Parameters Preference (code 67).
user’s guide40
