4.13.9 - FEED REFUSAL ADJUSTMENT
During the execution of a Recipe, the Feed Refusal Adjustment
automatically corrects the weight to be unloaded in relation to the weight
actually loaded. By activating this Function, after executing all the loaded
Ingredients, the equipment allots any possible differences in the loaded
weight in proportion to the programmed value of the Unloads, thus
optimizing the usage and reducing waste. Furthermore, after each Unload,
the equipment automatically corrects the following Unloads so that all the
loaded material is unloaded. This Function operates in a way that a Recipe
is weighed in which all of the Ingredients were weighed first and then all of
the Unloads were set with their respective Load and Unload Parameters.
1. Select the [
REF. ADJ.
] Function and confirm by pressing the OK key.
The [
YES
] or [
NO
] message will appear on the display depending on
the previously programmed setting.
2. Select the desired setting by pressing the q z keys.
[
YES
] the Function is active, [
NO
] the Function is not active.
3. Confirm by pressing the OK key. The equipment will return to the Special
Function Menu.
• If the Feed Refusal Adjustment Function is enabled, in the Skip to
Ingredient/Unload Function it is possible to select only the Ingredients/
Unloads that follow the one displayed.
• In the Recipe Execution Activity, if the current Recipe is programmed
with the Feed Refusal Adjustment but the programming order (first all
the Loads and then all the Unloads) has not been followed, the Recipe
will not be executed with the Feed Refusal Adjustment. After pressing
the Prog./Start key, the [
ERR-26
] message will appear on the display.
To continue with the execution press the OK key. To return to the Recipe
Programming Activity press the Prog./Start key.
user’s guide60
