AppeNdiX c 77
Appendix C
TECHNICAL SPECIFICATIONS
CPU .................................................... 8Bit 24MHz.
Program Memory ................................. 256KB
Data Memory ....................................... 8Mb
Clock .................................................. With Lithium Battery
Supervisor ........................................... Hardware
Display ................................................ LCD 70mm (2.8”) backlit 6x14 segments
Displaying Frequency ............................. 800ms
Visibility ............................................... 20m (66ft)
Keyboard ............................................. 19 mechanical keys
Converter ............................................ A/D 24Bit 2 channels
Conversion Speed ................................. 20ms
Min. Sensitivity ..................................... 0,76μV/div.
Converter Filter .................................... FIR and SINC3
Digital Filter ......................................... Programmable
Load Cells Supply Voltage ....................... +5Vdc (protected from overload and temp.)
Load Cells Sensitivity ............................. 0,1 ... 6,0mV/V
Load Cells Input .................................... Differential
Load Cells Connections .......................... 10 x 350 ohm Load Cells
Supply Voltage ...................................... 9 ... 32Vdc
Power Supply ....................................... 12W (with 4 Load Cells)
Alarm Output ....................................... 1,5 Ampére
Operating Temperature ......................... -15° ... +60°C (+5°F to +140°F)
Storage Temperature ............................ - 20° ... +60°C (-4°F to +140°F)
Maximum Humidity ............................... 90% not condensed
Maximum Altitude ................................. 3000m (9842ft)
Case ................................................... PC/ABS
Weight ................................................ 1,8kg (3.97lbs)
Dimensions .......................................... 248x225x120mm (9.76”x8.86”x4.72”)
Degree of Protection ............................. IP65
