Labrie MINIMAX - Monitor

40 Controls and Indicators
Figure 3-1 Monitor
Each time the operator turns the ignition key on, a complete bit test of the multiplexed system is
conducted. This test takes about 5 seconds to complete.
NOTE: A flashing green light on the monitor indicates that the power is on. This light should be
blinking steadily at 2 Hz during normal operation. If it blinks at a faster rate, it is a sign of a
problem with the monitor. A flashing red light on the monitor is also a sign of a problem. Call
LabriePlus for support.
The logo of Labrie Enviroquip Group appears momentarily on the monitor screen at the start of the
system (see Figure 3-2).
Figure 3-2 Labrie logo on the monitor screen
NOTE: If the Welcome Screen with the Labrie logo stays on continuously, there may be a
communication problem between the monitor and the master control module. Report this
problem to the maintenance personnel.
