Lakeshore 425 - Transverse Probes; Flexible Transverse Probes

1.5.2 Tran sverse Pro bes 5
| www.lakeshore.com
1.5.2 Transverse Probes
1.5.3 Flexible
Transverse Probes
FIGURE 1-6 Transverse probe
L (in) T (in) W (in) A (in)
Active
area (in)
Stem
material
Frequency
range
Usable full
scale ranges
Corrected
accuracy
(% rdg)
Operating
temp
range
Te mp
coefficient
(max) zero
Te m p
coefficient
(max)
calibration
HMMT-6J04-VR 4 ±0.125
0.061
max
0.180
±0.005
0.150
±0.050
0.040 dia
(approx)
Aluminum
DC to
800 Hz
HSE
35 G, 350 G,
3.5 kG, 35 kG
±0.20% to
30 kG;
±0.25%
30 to 35 kG
0 °C to
+75 °C
±0.09 G/°C -0.04%/°C
HMNT-4E04-VR 4 ±0.125
0.045
max
0.150
±0.005
Fiberglass
epoxy
DC to
10 kHz
HMMT-6J04-VF 4 ±0.125
0.061
max
0.180
±0.005
Aluminum
DC to
400 Hz
HST-4
350 G, 3.5 kG,
35 kG
±0.10% to
30 kG;
±0.15%
30 to 35 kG
±0.13 G/°C -0.005%/°C
HMNT-4E04-VF 4 ±0.125
0.045
max
0.150
±0.005
Fiberglass
epoxy
DC to
800 Hz
TABLE 1-2 Transverse probe
FIGURE 1-7 Flexible transverse probe
W (in) T (in) A (in)
Active
area (in)
Stem
material
Frequency
range
Usable full
scale ranges
Corrected
accuracy (% rdg)
Operating
temp
range
Te mp
coefficient
(max) zero
Te m p
coefficient
(max)
calibration
HMFT-3E03-VR
0.135
max
0.025
max
0.125
±0.005
0.040 dia
(approx)
Flexible
plastic
tubing
DC to
10 kHz
HSE
35 G, 350 G,
3.5 kG, 35 kG
±0.20% to 30 kG;
±0.25% 30 to 35 kG
0 °C to
+75 °C
±0.09 G/°C -0.04%/°C
HMFT-3E03-VF
DC to
800 Hz
HST-4
350 G, 3.5 kG,
35 kG
±0.10% to 30 kG;
±0.15% 30 to 35 kG
±0.13 G/°C -0.005%/°C
TABLE 1-3 Flexible transverse probe
