Lakeshore 425 - Chapter 7: Probes and Accessories

7.1 Ge n e r a l 59
| www.lakeshore.com
Chapter 7: Probes and Accessories
7.1 General
This chapter provides information on standard probes and the accessories available
for the Model 425 gaussmeter.
7.2 Models
The list of Model 425 model numbers follows:
Power cords—the instrument ships from Lake Shore with customer-selected power
cords as follows:
7.3 Accessories
Accessories are devices that perform a secondary duty as an aid or refinement to the
primary unit. A list of accessories for the Model 425 is as follows:
7.4 Rack Mounting
The Model 425 can be installed into a 483 mm (19 in) rack mount cabinet using the
optional Lake Shore Model RM-½ rack mount kit, or the Model RM-2 dual rack
mount shelf. The rack mount kit contains mounting ears, panel, handles, and screws
that adapt the front panel to fit into a 88.9 mm (3.5 in) tall full rack space. Refer to
FIGURE 7-1 for installation details.
Ensure that there is a 25 mm (1 in) clearance on both sides of the instrument after
rack mounting.
Model Description
425 Model 425 gaussmeter
425-HMXX-XXXX-XX
Model 425 gaussmeter with standard probe choice—specify selected probe number for
HMXX-XXXX-XX (refer to the list in section 1.5)
TABLE 7-1 Model description
VAC-120 Instrument shipped with U.S. power cord for 120 VAC
VAC-220 Instrument shipped with European power cord for 220 VAC
VAC-120-ALL Instrument shipped with U.S. power cord (120 VAC) and European power cord (220 VAC)
TABLE 7-2 Power cord option
Model Description
G-106-253 I/O mating plug
G-106-264 I/O mating connector shell
4060 Zero gauss chamber
MAN-425* Model 425 user manual
*RoHs compliant
TABLE 7-3 Accessories included with Model 425
Model Description of Accessories
4065 Large zero gauss chamber for gamma probe
HMCBL-6 User programmable cable with EEPROM (6 ft)
HMCBL-20 User programmable cable with EEPROM (20 ft)
HMPEC-10-U Probe extension cable with EEPROM (10 ft), uncalibrated
HMPEC-25-U Probe extension cable with EEPROM (25 ft), uncalibrated
HMPEC-50-U Probe extension cable with EEPROM (50 ft), uncalibrated
HMPEC-100-U Probe extension cable with EEPROM (100 ft), uncalibrated
RM-q Rack mount kit for one q-rack gaussmeter in 483 mm (19 in) rack
RM-2 Rack mount kit for two q-rack gaussmeter in 483 mm (19 in) rack
4030-12 Hall probe stand; 305 mm (12 in) post
4030-24 Hall probe stand; 610 mm (24 in) post
TABLE 7-4 Accessories available
