NOTE
Customer must use
5⁄ge
in (2 mm) hex
key to remove four existing screws
from sides of instrument.
Unit on right side mounting shown.
Unit on left side also possible.
Item Description P/N Qty
1 Rack mount ear 107-440 1
2 Rack mount support 107-442 1
3 Rack mount panel 107-432 1
4 Rack mount handle 107-051-01 2
5 Screw, 6-32 × ½ in 0-035 4
FHMS Phillips
6 Screw, 8-32 ×
3⁄i in 0-081 6
FHMS Phillips
Refer to
NOTE
