2D Missing Line (ML) Download Messages
For "SHot1" and "SHot2" refer to Horizontal Vector (HV) Download Message.
$PLTIT,ML,HD,HDunits,AZ,AZunits,INC,INCunits,SD,SDunits*csum<CR><LF>
$PLTIT, is the Criterion message identifier.
ML, Missing Line message type.
HD, Specifies horizontal distance measurement value.
HDunits, Specifies horizontal distance units.
F=feet, M=meters, Y=yards.
Note: Only International lasers include meters.
AZ, Azimuth dummy value (always 0.00)
AZunits, Specifies azimuth units.
D=degrees.
INC, Specifies inclination measurement value.
INCunits, Specifies inclination units.
D=degrees.
SD, Specifies slope distance measurement value.
SDunits Specifies slope distance units.
F=feet, M=meters, Y=yards.
Note: Only International lasers include meters.
*csum An asterisk followed by a hexadecimal checksum.
The checksum is calculated by XORing all the
characters between the dollar sign and the asterisk.
<CR> Carriage return.
<LF> Line feed.
Example:
SHot1:
$PLTIT,HV,6.00,Y,0.00,D,7.20,D,6.10,Y*68
SHot2:
$PLTIT,HV,5.90,Y,0.00,D,11.60,D,6.00,Y*5D
Calculated Missing Line:
$PLTIT,ML,8.10,Y,0.00,D,3.20,D,8.10,Y*74
Note: Only International lasers include meters.

• HDvalues, INCvalues, and SDvalues always include two decimal places:
X X.YY

0 = high quality target
1 = low quality target
• In the example above, shots 1 and 2 both used high quality targets
