Laser Technology TruPulse 200 User Manual

Section 1 - Introducing the LTI TruPulse 200
Page 3
Section 1 - Introducing the LTI TruPulse 200
Congratulations on the purchase of your TruPulse, a cost-effective professional rangefinder. This
compact and lightweight laser is a flexible tool for your measurement needs. The TruPulse includes
five measurement modes, five target modes, and serial data output.
Features of the TruPulse 200:
 Crystal clear optics and the heads up display lets you keep your eye on the target.
 "Thru-the-lens" viewing eliminates parallax issues so you know the laser energy is
traveling directly along your line of sight.
 The laser sensor and integrated tilt sensor measure slope distance, horizontal distance,
vertical distance, inclination, or instantly calculate the height of any object.
 The Target Mode allows you to select or eliminate targets; which helps yo
u take
the
most accurate measurement possible in a variety of field conditions.
 Adjustable eyepiece provides comfortable viewing for eye or sunglass wearers.
 Measurement data is available for download via wired RS232 serial and/or Bluetooth
wireless communication.
Operating Modes
Measurement Modes*
Slope Distance
Vertical Distance
Horizontal Distance
Inclination
3-Point Height Routine
2D Missing Line Routine
Target Modes
Standard
Continuous
Closest
Farthest
Filter
System Setup Modes
Units Selection
Bluetooth Enable
Tilt Sensor Alignment
* Domestic Lasers: feet or yards
* International Lasers: meters, feet or yards
1. FIRE button (power ON)
2.  (UP) button
3. (DOWN)
button
4. Adjustable
Eyepie
ce
5.
Diopter Adjustment Ring
6. Tripod / Monopod m
ount
7. Attach
ment
Point
(for neck strap and Foliage Filter Lens)
8. RS232 Data Port
9. Battery Compartment Cover
10. Receive Lens
11. Transmit Lens / Viewing Objective
Figure #1
