Section 6 - Target Modes
Page 25
Section 6 - Target Modes
The TruPulse has five Target Modes which allow you to select or eliminate targets and to take the
most accurate measurements possible in various field conditions.
1. From the Measurement Mode, press
for 4 seconds. The
active Target Mode appears in the Main Display.
2. Press
or to display the previous or next Target
Mode.
3.
Press to select the displayed Target Mode and return to
the Measurement Mode.
o Std = Standard: Single shot mode.
o Con = Continuous: Press-and-hold
. Once the target is
acquired, the TruPulse can continuously acquire
additional
tar
gets for a maximum of 10 seconds. The most recently
acquired target appears in the Main Display.
Note: The MULTI indicator is not displayed in this mode.
o CLO = Closest: Press-and-hold
. Once the initial target
is acquired, the TruPulse can acquire additional targets. The
MULTI indicator denotes that additional targ
ets have been
acquired. The clos
est acquired target always appears in th
e
Main Displa
y.
o FAr = Farthest: Press-and-hold
. Once the initial target
is acquired, the TruPulse can acquire additional targets. The
MULTI indicator denotes that additional targ
ets have been
acquired. The f
arthest acquired target always appears in th
e
Main Displa
y.
o Flt = Filter: In this mode the laser’s sensitivity is reduced
to
only
detect pulses returned from a reflector. Th
e optional
foliage filter
must be used in conjunction with this mode. In
this mode, measurements always include ‘F’ as the left most
character in the Main Display. Typical maximum distance is
107 meters (350 feet) to a 3-inch reflector.
• The selected Target Mode remains active until you repeat the above steps
and select a different Target Mode.
• Each time the TruPulse is powered ON, it will return to the same Target
Mode that was last used.
• In Closest and Farthest Modes, the minimum separation distance between
targets is approximately 20 meters (66 feet).
Figure #21
