LTI TruPulse 360R User’s Manual Page 10
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Buttons
The TruPulse 360R has three buttons. With the TruPulse 360R in your right hand and looking
through the eyepiece,
is located on top, near your index finger and and are located on the
top of the instrument.
Measurement Modes
Powers ON the unit.
Distance Measurement: fires the laser.
Inclination: Release “locks” tilt sensor in (1) Height
Measurement Mode and (2) Continuous Target Mode.
Height Routine
(HD) Fires the laser.
(INC) Release “locks” tilt sensor.
Target Modes
System Setup Modes
Selects option and returns to the Measurement Mode.
Calibration Routines
When “no””CAL” or “YES””CAL” displayed, press to
begin the Calibration Routine.
When “PASS” message displayed, exits the routine and
returns to the Measurement Mode.
When “FAiL” message displayed, the “no””CAL” option is
displayed.

(UP)
Measurement Modes
Press to scroll to the previous Measurement Mode.
Press-and-hold 4 seconds to access the Target Mode.
Height Routine
Missing Line Routine
Clears the last measurement and re-displays the previous
prompt.
Target Modes
System Setup Modes
Press to scroll to the previous option.
Calibration Routines
When “no””CAL” or “YES””CAL” displayed, press to
scroll to the previous option.
Press-and-hold 4 seconds to abort the calibration and return
to the Measurement Mode. Previous calibration is restored.
