LTI TruPulse 360R User’s Manual Page 33
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Slope Distance (SD)
Azimuth (AZ)
Inclination (INC)
Horizontal Distance (HD)
Vertical Distance (VD)
Height Routine (HT)
Section 5 - Measurement Modes
When you power ON the TruPulse 360R, the last used Measurement Mode will be active.
Press
or to display the previous or next Measurement Mode. Figure #20 shows six different
types of measurements that the TruPulse 360R e can take. For information about the Missing Line
Routine, see page 37.
Distance Measurements
The basic steps for taking any distance measurement:
1. Look through the eyepiece and use the crosshair to aim to the target.
2. Press-and-hold
. The LASER status indicator is displayed while the laser is active.
The laser remains active for a maximum of 10 seconds while acquiring data about the target.
o If the target is not acquired in the 10-second period, release
and repeat this step.
3. Once the measurement is displayed, release
. The measurement flashes one time, indicating
the measurement was downloaded. Then the measurement is displayed steady until you press
any button or the unit powers OFF.
Figure #20
