LTI TruPulse 360R User’s Manual Page 46
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Missing Line (ML) Download Messages
For "SHot1" and "SHot2" refer to Horizontal Vector (HV) Download Message (page 44).
$PLTIT,ML,HD,HDunits,AZ,AZunits,INC,INCunits,SD,SDunits*csum<CR><LF>
$PLTIT, is the Criterion message identifier.
ML, Missing Line message type.
HD, Specifies horizontal distance measurement value.
HDunits, Specifies horizontal distance units. F=feet, M=meters, Y=yards.
Note: Only International lasers include meters.
AZ, Specifies azimuth measurement value.
AZunits, Specifies azimuth units. D=degrees.
INC, Specifies inclination measurement value.
INCunits, Specifies inclination units. D=degrees.
SD, Specifies slope distance measurement value.
SDunits Specifies slope distance units. F=feet, M=meters, Y=yards.
Note: Only International lasers include meters.
*csum An asterisk followed by a hexadecimal checksum.
The checksum is calculated by XORing all the
characters between the dollar sign and the asterisk.
<CR> Carriage return.
<LF> Line feed.
Example:
SHot1: $PLTIT,HV,6.00,Y,179.40,D,7.20,D,6.10,Y*68
SHot2: $PLTIT,HV,5.90,Y,265.70,D,11.60,D,6.00,Y*5D
Calculated Missing Line: $PLTIT,ML,8.10,Y,316.90,D,3.20,D,8.10,Y*74
Note: Only International lasers include meters.
HDvalues, INCvalues, and SDvalues always include two decimal places:
X X.YY
0 = high quality target
1 = low quality target
In the example above, shots 1 and 2 both used high quality targets.
