LTI TruPulse 360R User’s Manual Page 53
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Section 11 - Troubleshooting
**See page 21 for Bluetooth troubleshooting information.
Problem Remedy
The unit does not power ON or
the LCD does not illuminate.
Press
.
Check and if necessary, replace the battery or batteries.
The target cannot be acquired. Make sure the unit is powered ON.
Make sure that nothing is obstructing the transmit and receive
lens.
Make sure the unit is held steady while pressing
.
Make sure that you press-and hold
as long as the laser is
active (10 second maximum).
Make sure that Filter (Flt) Target Mode is OFF if not using a
reflector.
The TruPulse 360R does not
have an OFF button.
Simultaneously press-and-hold and for 4 seconds.
To conserve battery power, the unit turns itself off if no button
presses are detected after a specified length of time:
• With Bluetooth OFF: 2 minutes
• With Bluetooth ON: 30 minutes
Incorrect measurements. Align the Tilt Sensor (page 22). If problem persists, contact
LTI for assistance. See inside front cover for LTI contact
information.
My Missing Line (ML) results
are off (or not within spec).
When performing the ML Routine, do not use handheld. For
most accurate results, the TruPulse 360R should be mounted
on a tripod or monopod, and use "good practice" (page 39).
To improve the accuracy of
Missing Line Results:
When aiming to point #2, ensure that the TruPulse 360R
is kept perpendicular to a specific point on the ground,
and do not use a rapid swinging motion to position the
TruPulse 360R.
Mount the TruPulse 360R on a monopod or tripod.
If using TruPulse 360R handheld, see page 39.
FAiL2, FAiL3, or FAil4 results
during user calibration.
Move to a more suitable location, remove metallic or
electronic objects from your person, and retry the Tilt Sensor
or Horizontal Angle Compass Calibration Routine.
