LTI TruPulse 360R User’s Manual Page 44
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Download Message Formats
Horizontal Vector (HV) Download Messages
$PLTIT,HV,HDvalue,units,AZvalue,units,INCvalue,units,SDvalue,units,*csum
<CR><LF>
where:
$PLTIT, is the Criterion message identifier.
HV, Horizontal Vector message type.
HDvalue, Calculated Horizontal Distance. Two decimal places.
units, F=feet Y=yards M=meters
Note: Only International lasers include meters.
AZvalue, Measured Azimuth . Two decimal places.
Percent slope is not downloaded.
units, D=degrees
INCvalue, Measured Inclination value. Two decimal places.
May be positive or negative value.
units, D=degrees
SDvalue, Measured Slope Distance Value. Two decimal places.
units, F=feet Y=yards M=meters
Note: Only International lasers include meters.
*csum An asterisk followed by a hexadecimal checksum.
The checksum is calculated by XORing all the
characters between the dollar sign and the asterisk.
<CR> Carriage return.
<LF> Optional linefeed.
• HDvalues, INCvalues, and SDvalues always include two decimal places:
X X.YY
0 = high quality target
1 = low quality target
• Closest and Farthest Target Modes: multiple targets can be acquired, however, the
download message corresponds to the value that appears in the Main Display.
Examples:
High Quality Target: $PLTIT,HV,18.00,F,185.20,D,6.90,D,18.00,F*66
Low Quality Target: $PLTIT,HV,7.01,M,0.00,D,3.00,D,7.01,M*64
Azimuth Only: $PLTIT,HV,,,187.10,D,8.40,D,,*64
Inclination Only: $PLTIT,HV,,,347.20,D,,,,*3F
Note: Only International lasers include meters.
