LTI TruPulse 360R User’s Manual Page 40
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Section 6 - Target Modes
The TruPulse 360R has five Target Modes, which allow you to select or eliminate targets
and to take the most accurate measurements possible in various field conditions.
1. From the Measurement Mode, press
for 4 seconds. The active Target
Mode appears in the Main Display.
2. Press
or to display the previous or next Target Mode.
3. Press
to select the displayed Target Mode and return to
the Measurement Mode.
o Std = Standard: Single shot mode.
o Con = Continuous: Press-and-hold
. Once the target is acquired,
the TruPulse 360R can continuously acquire additional targets for a
maximum of 10 seconds. The most recently acquired target appears in
the Main Display.
Note: The MULTI indicator is not displayed in this mode.
o CLO = Closest: Press-and-hold
. Once the initial target is
acquired, the TruPulse 360R e can acquire additional targets. The
MULTI indicator denotes that additional targets have been acquired.
The closest acquired target always appears in the Main Display.
o FAr = Farthest: Press-and-hold
. Once the initial target
is acquired, the TruPulse 360R can acquire additional targets. The
MULTI indicator denotes that additional targets have been
acquired. The farthest acquired target always appears in the
Main Display.
o Flt = Filter: In this mode, the laser’s sensitivity is reduced to
only detect pulses returned from a reflector. The optional
foliage filter must be used in conjunction with this mode. In
this mode, measurements always include ‘F’ as the left-most
character in the Main Display. Typical maximum distance is
107 meters (350 feet) to a 3-inch reflector.

• The selected Target Mode remains active until you repeat the
above steps and select a different Target Mode.
• Each time the TruPulse 360R is powered ON, it returns to the
same Target Mode that was last used.
• In Closest and Farthest Modes, the minimum separation distance
between targets is approximately 20 meters (66 feet) for
non-cooperative targets. Cooperative targets could require greater
separation.
Figure #26
