LTI TruPulse 360R User’s Manual Page 18
Copyright (c) [2017] Laser Technology, Inc. All Rights Reserved. Unauthorized duplication, in whole or in part, is strictly prohibited.
Section 4 - System Setup
Figure #10 shows an overview of the System Setup Mode which can be accessed from the
Measurement Mode. Each option is described separately in the following sections.
1. From the Measurement Mode, press and hold
for 4 seconds. “UnitS” will appear in the Main
Display as shown in Figure #10 below.
2. Press
or to display the previous or next option.
3. Press
to select an option.
Figure #10
