LAUNCH

X-431 Module S2 User Manual

to the car battery for power.

Battery clamps

cable

Used to connect the sensor module to the

car battery only using the Actuator module.

USB cable

Used to connect the sensor module and

diagnostic tool, and send the signal collected

by the sensor module to the diagnostic tool

for waveform display.

6-way breakout

lead

The 6-way lead is available in 3 joint sizes:

1.0mm, 1.6mm, 2.8mm

The lead can be easily connected to the

existing car harness interface, which is

convenient for reading sensor signals. The

output signal is connected to the CH1/CH2

input port of the sensor module through the

HT30 test leads from the 4mm banana

connector at the other end of the lead.
