LAUNCH X-431 Module S2 User Manual
8
7
Multimeter test
pen (black + red)
During a multimeter function test, it must be
connected to the COM and V/Ω/C terminals
of the sensor module.
2
8
Back Probe Pins
Suite
They are mainly used for piercing the
insulation of wires to allow for automotive
electrical measurements without causing
damage to the wires. Additionally they can
be used as pin-tip probes while working with
small circuit boards.
1
9
Power adaptor
To charge the sensor module together with
the included USB cable.
1
