LAUNCH X-431 Module S2 User Manual
15
Output channel: CH1
Output type: DC voltage
Drag the yellow slider to change the output voltage value of CH1 to simulate the
intake air pressure change.
4) Throttle position sensor
Output channel: CH1, CH2
Output type: DC voltage
Drag the yellow slider to change the output voltage value of CH1.
Drag the green slider to change the output voltage value of CH2.
