On-screen Buttons:
Select All: Selects all items of the current page. To select certain data stream item, just check the box before
the item name.
Select All: Selects all items of all pages.
Unselect: Deselects all data stream items.
OK: Conrms and jumps to the next step.
After selecting the desired items, tap or click “OK” to enter the data stream reading page.
Fig. L-16
Notes:
1. If the value of the data stream item is out of the range of the standard (reference) value, the whole line will display
in red. If it complies with the reference value, it displays in blue (normal mode).
2. The indicator 1/X shown on the bottom of the screen stands for the current page/total page number. Swipe the
screen from the right/left to advance/return to the next/previous page.
There are 3 types of display modes available for data viewing, allowing you to view various types of
parameters in the most suitable way.
• Value – this is the default mode which displays the parameters in texts and shows in list format.
• Graph – displays the parameters in waveform graphs.
• Combine – this option is mostly used in graph merge status for data comparison. In this case, different
items are marked in different colors.
On-screen Buttons:
: Tap or click it to view the waveform graph of the current data stream item.
To Next Page
