5. Touch the "Phistogram" tab, then touch inside the Slice Direction field and select
Horizontal or Vertical slice from the pop-up menu.
6. Touch inside the Slice Center field and enter a value, using the pop-up keypad.
7. Touch inside the Slice Width field and enter a value, using the pop-up keypad.
Note: You can use the front panel Adjust knobs to move the Slice Center line and the Slice Width boundary lines.
Persistence Trace Range
This math operation has a field where you can enter the percent of the persistence trace population
to use in creating a new waveform.
Persistence Sigma
This math operation has a field where you can enter a scale, measured in standard deviations, by
which to create a new waveform.
