Master Analysis Package (XMAP)
This package provides a comprehensive set of signal WaveShape Analysis tools that provide
insight into the wave shape of complex signals. Additional analysis capability provided by XMAP
includes:
y Jitter and Timing Analysis package (JTA2)
y 8 math traces total (4 additional)
y Parameter Math: add, subtract, multiply, or divide two different parameter measurements
y User-definable parameter measurements and math functions, using VBScripting with MS
Excel and MATLAB
y Histograms expanded with 19 histogram parameters and up to 2 billion events
y Trend (datalog) of up to one million events
y Track graphs of any measurement parameter
y FFT capability expands the basic FFT to include; power averaging, power density, real and
imaginary components, frequency domain parameters and FFT on up to 25 Mpts.
y Narrow Band power measurements
y Correlation function
y Interpolation
y Sparse
Jitter and Timing Analysis Package (JTA2)
This package provides jitter timing and analysis using JitterTrack (time), Histogram (statistical) and
JitterFFT (frequency) views for common timing parameters, and other useful tools.
y Jitter and Timing parameters with JitterTrack graphs of:
Cycle-to-Cycle
N-Cycle
N-Cycle with Start selection
Frequency
Period
Half Period
Width
Time Interval Error
Setup
Hold
Skew
Duty Cycle
Duty Cycle Error (Delta Width)
y edge@lv parameter (counts edges)
y Histograms expanded with 19 histogram parameters and up to 2 billion events
y Trend (datalog) of up to one million events
y Persistence Histogram; Persistence Trace
Disk Drive Measurement Package (DDM2)
This package provides disk drive parameter measurements and related mathematical functions for
performing disk drive WaveShape Analysis.
