Local Feature Parameters
lbase Local Base
Definition
The value of the baseline for a local feature.
Description
The average value of the local baselines for all local features between the
parameter cursors is displayed as lbase. For histograms, each individual
baseline value for all local features between the parameter cursors is
provided.
Parameter Settings
Selecting this parameter from the Measure menus prompts you for a
hysteresis setting, which allows you to set the hysteresis value to a
specified number of vertical divisions.
Example
